Model

CW-7500AN

Voltage

AC380V

Frequency

50Hz

Current

8~13 A

Compressor power

4.54KW

6.05HP

Refrigerating capacity

49445Btu/h

14.5KW

12500Kcal/h

Refrigerant

R-22

Refrigerant charge

3600g

Precision

Capillary

Reducer

±1℃

Protection

Overcurrent protection for compressor, flow alarm, over temperature alarm

Pump power

0.55KW

Tank capacity

30L

Inlet and outlet

Rp1/2"

Max. lift

28M

Max. flow

58L/min

N.W

280Kgs

G.W

305Kgs

Dimension

110X65X140 cm (L X W X H)

Package dimension

129X85X165 cm (L X W X H)
